Product

Stainless Steel Woven Mesh

Raw Material

SS 201,304,304L, 316,316L, 430,ect stainless steel wire

Diameter

0.0008″-0.12″

Mesh

2-635mesh

Open Area

25-84.6

Roll Width

Max 240″

Roll Length

Max 2000′

Application

Filters ,sieve,chemical industry, mine industry, etc

Packaging

Inner kraft paper, outside plastic cloth, put into wooden pallet or case

Specification sheet of the plain weave woven wire cloth

Mesh/Inch

Absolute micron retention (μm)

Weight (kg/m2)

Cloth Thickness (mm)

80 × 300

32 - 36

0.98

0.25

80 × 400

36 - 45

0.82

0.23

50 × 250

56 - 63

1

0.32

50 × 280

71 - 75

1

0.32

40 × 200

75 - 80

1.3

0.4

30 × 150

80 - 100

1

0.5

24 × 110

100 - 112

2.5

0.76

22 × 140

140 - 170

2.1

0.66

20 × 150

160 - 180

1.55

0.5

20 × 150

170 - 190

1.6

0.55

18 × 100

200 - 210

2.05

0.69

14 × 110

220 - 240

2.15

0.72

12 × 95

240 - 260

2.3

0.79

14 × 88

280 - 300

3.15

0.76

10 × 90

270 - 290

2.5

0.93

12 × 64

280 - 300

4.1

1.21

10 × 70

315 - 335

3

1.04

8 × 85

330 - 350

2.5

0.93

Specification of the twill weave stainless steel wire cloth.

Mesh/Inch

Absolute micron retention (μm)

Weight (kg/m2)

Cloth Thickness (mm)

510 × 3600

4-5

0.3

0.06

400 × 2800

5-6

0.36

0.06

375 × 2300

6-7

0.39

0.08

325 × 2300

7-8

0.47

0.09

260 × 1550

8-10

0.68

0.12

250 × 1400

11-12

0.68

0.12

200 × 1400

11-13

0.75

0.14

130 × 700

13 - 15

1.6

0.28

200 × 1120

15 - 17

0.95

0.16

165 × 1400

15 - 18

0.7

0.15

165 × 1100

20 - 21

0.9

0.16

80 × 700

34 - 36

1.2

0.26

40 × 560

71 - 80

1.7

0.39

30 × 360

95 - 106

2.6

0.54

30 × 250

100 - 112

3.2

0.65

20 × 260

110 - 120

3.1

0.67

28 × 560

106 - 112

1.95

0.46

24 × 300

112 - 118

2.85

0.63
